Meegeleverde accessoires
- 1x Blackmagic Pocket Cinema Camera AC Adapter
- 2x Canon LP-E6 battery
- 1x CFast card 2.0 256GB 510MB/s
- 1x Canon LP-E6 battery charger
- 1x Blackmagic Pocket Cinema Camera 4K
- 1x CFast Cardreader + USB cable
- 1x D-Tap > BMPCC cable
- 1x Swit Portable D-tap battery charger
- 1x Swit D-tap Connector cable
- 1x BMPCC Smallrig Cage whiteh tophandle
- 2x Swit Pocket V-mount battery 98Wh - for BMPCC
- 1x Wooden Camera Offset V-Lock Base Station
- 1x Bodycap
- 1x m4 (5/32) Allen key
Top specs
- 4/3" Sensor
- DCI 4K 60 fps
- Dual Native ISO to 25,600
- 13 stops dynamic range
De Blackmagic Design Pocket Cinema Camera 4K MFT heeft een 4/3 "-sensor voor het maken van 4096 x 2160 DCI 4K-beelden met snelheden tot 60 fps in verschillende codecs, waaronder Blackmagic Raw (BRAW): Constant Bitrate 3:1, 5:1, 8:1, 12:1 en Constant Quality Q0 and Q5 recording, en verschillende ProRes 422-opties Slow motion-snelheden tot 120 fps in cropped Full HD.
De MFT lensvatting maakt het mogelijk om originele, lichtgewicht MFT lenzen te gebruiken. Een dual-native ISO tot 25.600 is ideaal bij weinig licht en een dynamisch bereik van 13 stops levert rijke HDR-beelden op. De camera heeft een Mini XLR Mic/Line Level (+48 V Phantom Power) Input.], een 3.5 mm Stereo Mic/Line Level Input en een 3.5 mm Stereo Headphone Output. De display is 5 inch. De body is van Carbon Fiber en weegt 680 gram. De afmeting is 177.8 x 96.52 x 86.36 mm.
Deze set komt met 2 compacte baby v-lock accu's en twee backup LP-E6 accu's om gemakkelijk een dag door te komen. Met de v-lock accu kan je tot 5 uur per accu opnemen. De Smallrig cage met tophandle maakt deze set helemaal af.
| Image Sensor |
| Image Sensor Size |
18.96 x 10.00 mm (4/3") |
| Sensor Type |
CMOS |
| Shutter Type |
Rolling Shutter |
| ISO |
100 to 25,600 (Native) |
| Advertised Dynamic Range |
13 Stops |
| Camera |
| Lens Mount |
Micro Four Thirds |
| Lens Communication |
Yes |
| Built-In ND Filter |
None |
| Built-In Microphone Type |
Stereo |
| Recording Media |
1 x CFast 2.0 Card Slot
1 x SDXC UHS-II Card Slot |
| Internal Recording |
| Raw Recording |
BlackmagicRAW:
Constant Bitrate 3:1, 5:1, 8:1, 12:1 recording for Blackmagic RAW
Constant Quality Q0 and Q5 recording for Blackmagic RAW |
| Recording Modes |
ProRes 422HQ:
4096 x 2160 at 23.98/24/25/29.97/30/50/59.94/60 fps (117.88 MB/s)
3840 x 2160 at 23.98/24/25/29.97/30/50/59.94/60 fps (110 Mb/s)
1920 x 1080p at 23.98/24/25/29.97/30/50/59.94/60/120 fps (27.5 MB/s)
ProRes 422:
4096 x 2160 at 23.98/24/25/29.97/30/50/59.94/60 fps (78.63 MB/s)
3840 x 2160 at 23.98/24/25/29.97/30/50/59.94/60 fps (73.6 MB/s)
1920 x 1080p at 23.98/24/25/29.97/30/50/59.94/60/120 fps (18.4 MB/s)
ProRes 422LT:
4096 x 2160p at 23.98/24/25/29.97/30/50/59.94/60 fps (54.63 MB/s)
3840 x 2160 at 23.98/24/25/29.97/30/50/59.94/60 fps (51 MB/s)
1920 x 1080p at 23.98/24/25/29.97/30/50/59.94/60/120 fps (12.75 MB/s)
ProRes 422 Proxy:
4096 x 2160 at 23.98/24/25/29.97/30/50/59.94/60 fps (24.25 MB/s)
3840 x 2160 at 23.98/24/25/29.97/30/50/59.94/60 fps (22.4 MB/s)
1920 x 1080p at 23.98/24/25/29.97/30/50/59.94/60/120 fps (5.6 MB/s) |
| External Recording |
| Video Output |
4:2:2 10-Bit via HDMI: 1920 x 1080p at 23.98/24/25/29.97/30/50/59.94/60 fps |
| Raw Output |
USB:
4096 x 2160 12-Bit at 23.98/24/25/29.97/30/50/59.94/60 fps
3840 x 2160 12-Bit at 23.98/24/25/29.97/30/50/59.94/60 fps
1920 x 1080 12-Bit at 23.98/24/25/29.97/30/50/59.94/60 fps |
| Interfaces |
| Video Connectors |
1 x HDMI Output |
| Audio Connectors |
1 x 3-Pin Mini XLR Mic/Line Level (+48 V Phantom Power) Input
1 x 1/8" (3.5 mm) Stereo Mic/Line Level (+48 V Phantom Power) Input
1 x 1/8" (3.5 mm) Stereo Headphone Output |
| Other I/O |
1 x USB Type-C Video Output
1 x 3.5 mm Timecode Input (Shared with 3.5 mm Mic/Line input) |
| Wireless Interfaces |
Bluetooth Control |
| Display |
| Display Type |
LCD |
| Screen Size |
5" |
| Touchscreen |
Yes |
| Screen Resolution |
1920 x 1080 |
| Power |
| Battery Type |
Canon LP-E6 |
| Power Connectors |
1 x 2-Pin LEMO (12 to 20 VDC) Input |
| Environmental |
| Operating Temperature |
32 to 104°F / 0 to 40°C |
| Storage Temperature |
-4 to 113°F / -20 to 45°C |
| Operating Humidity |
0 to 90% |
| General |
| Accessory Mount |
1 x 1/4"-20 Female Thread |
| Tripod Mounting Thread |
1/4"-20 |
| Material of Construction |
Carbon Fiber |
| Dimensions |
7 x 3.8 x 3.4" / 177.8 x 96.52 x 86.36 mm |
