Die EOS C70 ist die erste Kinokamera von Canon mit einem RF-Anschluss. Die Kamera verfügt über einen 4K Super 35MM DGO-Sensor (Dual Gain Output) und nimmt bis zu 4K 120fps in verschiedenen Codecs auf.

Durch den Dual Gain Output-Sensor hat die C70 einen beworbenen Dynamikumfang von bis zu 16 Stopps. Dies ist möglich, weil das DGO-System zwei separate Verstärkungswerte für jede Fotodiode auf dem Sensor kombiniert und so das Rauschen reduziert.

Die Kamera ist kompakt, leicht und dank der einfachen Menüführung und des Touchscreens von Canon leicht zu bedienen. Darüber hinaus verfügt die Kamera über einen integrierten Nd-Filter und einen HDMI-Eingang in voller Größe. Damit ist die C70 perfekt für Hobbyfotografen.

Canon C70 Specs

Image Sensor

Image Sensor Size	26.2 x 13.8 mm (Super35)
Sensor Type	CMOS
Sensor Resolution	Actual: 4206 x 2280 (9.6 MP) Effective: 4096 x 2160 (8.85 MP)
Sensor Windowing	2048 x 1080 in 16:9 When Recording in Super 16
Pixel Pitch	6.4 µm
Color Filter	Bayer
Shutter Type	Rolling Shutter
ISO	100 to 102,400
Gain	-6 to 54 dB (Native) -2 to 54 dB (Expanded)
Advertised Dynamic Range	16 Stops

Camera

Lens Mount	Canon RF
Lens Communication	Yes
Shutter Speed	1/12 to 1/2000 sec (In 60p Mode) 1/15 to 1/2000 sec (In 50p Mode)
Shutter Angle	11 to 360°
Built-In ND Filter	Mechanical Filter Wheel with Clear, 2 Stop (1/4), 4 Stop (1/16), 6 Stop (1/64), 8 Stop (1/256), 10 Stop (1/1024) ND Filters
Built-In Microphone Type	Stereo Mono
Recording Media	2 x SDXC/SDHC Card Slots
Variable Frame Rates	DCI 4K: 12 Up to 120 fps DCI 2K (Windowed): 12 Up to 180 fps

Internal Recording

Recording Modes	H.264/H.265/MP4/XF-AVC/XF-AVC Proxy 4:2:2 10-Bit: 4096 x 2160p up to 23.98/24/25/29.97/50/60 fps (160 to 260 Mb/s)  3840 x 2160p up to 23.98/24/25/29.97/50/60 fps (160 to 260 Mb/s)  2048 x 1080p up to 23.98/24/25/29.97/50/60 fps (50 Mb/s)  1920 x 1080p up to 23.98/24/25/29.97/50/60 fps (50 Mb/s)  H.264/H.265/MP4/XF-AVC/XF-AVC Proxy 4:2:2 10-Bit: 4096 x 2160p up to 119.88/120 fps  3840 x 2160p up to 119.88/120 fps  H.264/H.265/MP4/XF-AVC/XF-AVC Proxy 4:2:2 8-Bit: 2048 x 1080p up to 179.82/180 fps  1920 x 1080p up to 179.82/180 fps  H.264/H.265/MP4/XF-AVC/XF-AVC Proxy 4:2:0 8-Bit: 2048 x 1080p up to 23.98/24/25/29.97/50/59.94 fps (24 to 35 Mb/s)  1920 x 1080p up to 23.98/24/25/29.97/50/59.94 fps (24 to 35 Mb/s)  H.264/H.265/MP4/XF-AVC/XF-AVC Proxy 4:2:2 10-Bit: 4096 x 2160p up to 23.98/24/25/29.97/50/59.94 fps (135 to 225 Mb/s)  3840 x 2160p up to 50/59.94 fps (135 to 225 Mb/s)  2840 x 1080p up to 23.98/24/25/29.97/50/59.94 fps (50 Mb/s)  1920 x 1080p up to 23.98/24/25/29.97/50/59.94 fps (50 Mb/s)  1280 x 720p up to 50/59.94 fps (12 Mb/s)  H.264/H.265/MP4/XF-AVC/XF-AVC Proxy 4:2:0 10-Bit: 4096 x 2160p up to 23.98/24/25/29.97/50/59.94 fps (100 to 170 Mb/s)  3840 x 2160p up to 23.98/24/25/29.97/50/59.94 fps (100 to 170 Mb/s)  2048 x 1080p up to 23.98/24/25/29.97/50/59.94 fps (35 Mb/s)  1920 x 1080p up to 23.98/24/25/29.97/50/59.94 fps (35 Mb/s)  1280 x 720p up to 50/59.94 fps (9 Mb/s)  H.264/H.265/MP4/XF-AVC/XF-AVC Proxy 4:2:2 10-Bit: 4096 x 2160p up to 119.88/120 fps  3840 x 2160p up to 119.88/120 fps  2048 x 1080p up to 179.82/180 fps  1920 x 1080p up to 179.82/180 fps  H.264/H.265/MP4/XF-AVC/XF-AVC Proxy 4:2:0 8-Bit: 4096 x 2160p up to 23.98/24/25/29.97/50/59.94 fps (150 Mb/s)  3840 x 2160p up to 23.98/24/25/29.97/50/59.94 fps (150 Mb/s)  2048 x 1080p up to 23.98/24/25/29.97/50/59.94 fps (35 Mb/s)  1920 x 1080p up to 23.98/24/25/29.97/50/59.94 fps (35 Mb/s)  1280 x 720p up to 50/59.94 fps (8 Mb/s)  H.264/H.265/MP4/XF-AVC/XF-AVC Proxy 4:2:2 8-Bit: 4096 x 2160p up to 119.88/120 fps  3840 x 2160p up to 119.88/120 fps  2048 x 1080p up to 179.82/180 fps  1920 x 1080p up to 179.82/180 fps
Gamma Curve	Canon Log 2, Canon Log 3, HDR-HLG, HDR-PQ, Wide DR
Audio Recording	4-Channel 24-Bit 48 kHz LPCM Audio
Still Image Support	JPEG

External Recording

Video Output

4:2:2 10-Bit via HDMI: 4096 x 2160p at 23.98/24/25/29.97/50/59.94 fps 3840 x 2160p at 23.98/24/25/29.97/50/59.94 fps 1920 x 1080p at 23.98/24/25/29.97/50/59.94 fps 2048 x 1080p at 23.98/24/25/29.97/50/59.94 fps 1280 x 720p at 23.98/24/25/29.97/50/59.94 fps

Interfaces

Video Connectors	1 x HDMI Output
Audio Connectors	2 x Mini XLR Mic/Line Level (+48 V Phantom Power) Input 1 x 1/8" / 3.5 mm Stereo Input 1 x 1/8" / 3.5 mm Stereo Headphone Output
Other I/O	1 x USB Type-C Control, Video Input/Output 1 x BNC Timecode Input/Output 1 x 2.5 mm LANC Control

Display

Display Type	Articulating LCD
Size	3.5"
Resolution	2,760,000 Dot

EVF

EVF	Optional, Not Included

Power

Battery Type	Canon BP-A Series
Power Connectors	1 x Barrel (11.5 to 20 VDC) Input

Environmental

Operating Temperature	32 to 104°F / 0 to 40°C (Recommended)
Operating Humidity	85% (Recommended)

General

Tripod Mounting Thread1/4"-20 Female (Bottom)
1/4"-20 Female (Side)Dimensions6.3 x 5.1 x 4.6" / 160 x 130 x 116 mmW

Downloads

• Eosc70-im3-en
